Cấu tạo van bi nhựa UPVC/PPH/CPVC rắc co
Mô tả sản phẩm
- Van bi 2 rắc co
- Chất liệu : U-PVC/ PPH/CPVC
- Kích cỡ : DN15, DN20, DN25, DN32, D40, DN50, DN65, DN80, DN100
- Kiểu kết nối : dán keo
- Standard : ANSI, DIN, JIS, CNS
- Working pressure : 150PSI
- Môi trường làm việc : UPVC (0-45℃)
Bản vẽ chi tiết van :
SPECIFICATION OF MATERIAL
| Item | Parts | Material | PCS |
| 1 | Handle | ABS | 1 |
| 2 | Stem | UPVC/PPH/ CPVC | 1 |
| 3 | Stem O-ring | EPDM/VITON | 2 |
| 4 | Union Nut | UPVC/PPH/ CPVC | 2 |
| 5 | Seat | PTFE | 2 |
| 6 | Seat O-ring | EPDM/VITON | 1 |
| 7 | Connector | UPVC/PPH/ CPVC | 2 |
| 8 | Ball | UPVC/PPH/ CPVC | 1 |
| 9 | Body | UPVC/PPH/ CPVC | 1 |
| 10 | Seat | UPVC/PPH/ CPVC | 1 |
| 11 | Seat O-ring | EPDM/VITON | 1 |
| 12 | End O-ring | EPDM/VITON | 1 |
| 13 | Cap | ABS | 1 |
| SIZE | A | B | L | H | P | E | S1 |
| 15(1/2″) | 85.3 | 54.2 | 106.0 | 49.8 | 21.8 | 31.2 | 5.2 |
| 20(3/4″) | 89.8 | 63.1 | 115.0 | 55.0 | 23.7 | 33.2 | 5.0 |
| 25(1″) | 105.8 | 73.7 | 126.5 | 64.4 | 25.5 | 40.3 | 5.3 |
| 32(1-1/4″) | 116.0 | 84.5 | 142.7 | 75.2 | 29.3 | 52.0 | 6.8 |
| 40(1-1/2″) | 128.0 | 97.7 | 156.5 | 88.3 | 32.6 | 52.0 | 7.2 |
| 50(2″) | 139.6 | 117.5 | 172.0 | 104.3 | 35.7 | 71.0 | 7.2 |
| 65(2-1/2″) | 205 | 149.5 | 240 | 146.0 | 45.7 | 84.5 | 8.0 |
| 80(3″) | 205 | 168.6 | 266 | 152.3 | 49.7 | 84.2 | 8.6 |
| 100(4″) | 248 | 210.0 | 316 | 181.0 | 59.5 | 120.7 | 10.0 |
| SIZE | D | ANSI | DIN | JIS | CNS | ||||
| d1 | d2 | d1 | d2 | d1 | d2 | d1 | d2 | ||
| 15(1/2′) | 15 | 21.54 | 21.23 | 20.30 | 20.10 | 22.40 | 21.73 | 22.40 | 21.90 |
| 20(3/4′) | 20 | 26.87 | 26.57 | 25.30 | 25.10 | 26.45 | 25.69 | 26.40 | 25.90 |
| 25(1′) | 25 | 33.65 | 33.27 | 32.30 | 32.10 | 32.55 | 31.70 | 34.50 | 33.90 |
| 32(1-1/4′) | 32 | 42.42 | 42.04 | 40.30 | 40.10 | 38.60 | 37.65 | 42.50 | 41.90 |
| 40(1-1/2″) | 40 | 48.56 | 48.11 | 50.30 | 50.10 | 48.70 | 47.74 | 48.60 | 47.90 |
| 50(2″) | 50 | 60.63 | 60.17 | 63.30 | 63.10 | 60.80 | 59.78 | 60.60 | 59.90 |
| 65(2-1/2″) | 65 | 73.38 | 72.85 | 75.30 | 75.10 | 76.60 | 75.68 | 76.70 | 75.90 |
| 80(3′) | 80 | 89.31 | 88.70 | 90.40 | 90.10 | 89.60 | 88.55 | 89.70 | 88.90 |
| 100(4″) | 100 | 114.76 | 114.10 | 110.40 | 110.10 | 114.70 | 113.60 | 115.00 | 113.80 |
